Topographical survey deliverables are easiest to get right when the brief starts from the design and works backwards to the survey. A topographical survey records existing ground, but what it must deliver depends on what the designer will do with that record.
Quick Answer
Before you brief the surveyor, ask the designer four things: what they are designing, which surface they need, which features matter, and which file format their software opens. Those answers set the extent, the detail density, the surfaces and the delivery format. A brief written from the site boundary instead of the design task is the most common reason a survey has to be extended or redone.
What the price of the survey depends on is covered in our article on topographical survey cost. This one is about deciding what to ask for, so that the design team can use the survey the day it arrives.
Choose topographical survey deliverables from the design task
The same site needs a different survey for a road, a building platform or a drainage scheme, because each design asks a different question of the ground.
| Design task | What it needs from the survey |
|---|---|
| Building platform or terrace | A ground surface for cut and fill, levels at the boundary, existing structures and trees |
| Road or access | A surface along and beyond the route, kerbs and edges, existing crossings and drainage |
| Stormwater and drainage | Inverts, channels, low points and the fall of the ground across and beyond the site |
| Services and connections | Visible service features, manholes and chambers, and their levels |
A brief that names the design task lets the surveyor choose the right detail and coverage. A brief that only names the site leaves the surveyor to guess.
Naming the task also helps when topographical survey deliverables are compared between providers. Two quotes for a topographical survey of the same site can describe very different work. Two quotes for a survey that supports a named drainage design and a named building platform are pricing the same thing.
Extent follows the design, not the boundary
Many designs depend on ground outside the site: where water arrives from, where a road ties in, where a level must match a neighbour. Tell the surveyor where the design interacts with its surroundings, and the extent can be set to cover it.
Detail density follows the decisions
Say which features the designer will design around and which can be omitted. Detail that nobody will use costs time on site. Detail that is missing costs a return visit.
Surfaces follow the calculation
If the designer will calculate earthworks or check falls, they need a terrain model or triangulated surface, not only a contour plan drawn from one.
Format follows the software
Name the file format and version your design software opens, and the layer or coding convention the design team uses. Name the coordinate system and height datum as well, in words and by its code in the EPSG registry.
Key point
The designer, not the site, decides what the survey must deliver. A short conversation with the designer before the brief is issued is the cheapest scoping step in the whole project.
What a usable delivery typically contains
Most design teams expect four topographical survey deliverables, and it helps to name each one in the brief rather than assume it.
The first is a contour plan in CAD format. The second is a digital terrain model or triangulated surface. The third is a schedule of spot levels and detail points. The fourth is a survey report stating the datum and control used. Data captured from the air by an aerial survey or on the ground with GPS and GNSS equipment can feed the same deliverables, so the brief should describe the output it needs rather than prescribe the method.
Briefing a topographical survey for a design team?
Tell us what is being designed. We will propose the extent, detail and file set.
Ask us to scope the briefWho should write the brief
The person commissioning the survey should own the brief, with the designer supplying the design questions and the surveyor reviewing it before it is issued.
That review takes little time and catches the common gaps: an extent that stops at the boundary, a surface nobody asked for, or a format the design software cannot read. On civil and construction projects the same brief later supports setting out, so getting the reference and format right at this stage saves effort again further down the line. The same logic runs through our construction survey brief: decisions written down before the appointment cost less than decisions made on site. When the topographical survey deliverables are listed in the brief, the surveyor can confirm before fieldwork that each one will be produced.
Key point
Agreeing topographical survey deliverables in the brief is what makes quotes comparable, and what lets the design team start work the day the files arrive.
Ready to commission the survey?
Send the site plan and the design task. We will price the deliverables your team will use.
Get a topographical survey quoteWhere survey cannot help you
A well-scoped brief makes a topographical survey usable, but some design questions sit outside what a survey of existing ground can answer.
A topographical survey records what can be seen and measured on the surface. It cannot show buried services that have no visible feature, and it cannot record ground hidden beneath dense vegetation or water without additional work. It cannot predict how the ground will change once work starts. And it cannot choose the design reference on the designer's behalf.
What it can do is record existing ground against a stated reference, in the form the design team asked for, with its limits written down. That is the foundation every later stage of the design is built on.
Need levels and setting out after the design?
We can carry the same reference from survey through to construction.
